Specifications
Current rating: 1.5A AC/DC Max.
Voltage Range: 125V AC,DC
Withstand Voltage: 500V AC/Minute
Contact Resistance: 20 mΩ Max. before Environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -40℃ to 105℃
Applicable PC Board Thickness: 1.6mm
Reference
Mates with 2031P Header
