Specifications
Current rating: 2A AC,DC Max. (AWG 24)
Voltage Range: 250V AC,DC
Withstand Voltage: 800V AC/Minute
Contact Resistance: 10 mΩ Max. before Environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -25℃ to 85℃
Reference
Specification is same as 2009T series.
Mates with 2008S Board-in Housing
