Specifications
Current rating: 3A AC/DC Max. (AWG 22)
Voltage Range: 250V AC,DC
Withstand Voltage: 800V AC/Minute
Contact Resistance: 10 mΩ Max. before environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -25℃ to 85℃
Applicable Wire: AWG 22 to AWG 28
Applicable PC Board Thickness: 1.6mm
Reference
Use with 2509T, 2519T Terminal
