Specifications
Current rating: 5A AC/DC Max. (AWG 20)
Voltage Range: 300V AC,DC
Withstand Voltage: 1500V AC/Minute
Insulation Resistance: 1000 MΩ Min.
Contact Resistance: 10 mΩ Max. before environment test
Temperature Range: -40℃ to 100℃
Applicable Wire: AWG 16 to AWG 22
Applicable PC Board Thickness: 1.6mm
Reference
Mates with 3969T Board-in Terminal
