Specifications
Current rating: 20A DC/AC Max. (with 2.5mm2 wire)
Voltage Range: 24V AC,DC
Withstand Voltage: 1000V AC/Minute
Insulation Resistance: 1000 MΩ Min.
Contact Resistance: 5 mΩ Max. before environment test
Temperature Range: -30℃ to 125℃
Wire Range: 0.5 mm2 to 2.5 mm2 (AWG 18 – 13)
Reference
Use with 66501T Pin-Contact Terminal
Mates with 66502S Receptacle Housing
