Specifications
Current rating: 4A(Pitch 6.0mm),0.7A(Pitch 2.54mm,5.08mm)
Voltage Range: 200V AC,DC
Withstand Voltage: 1000V AC/Minute(Pitch 6.0mm)
2000V AC/Minute(Pitch 5.08mm)
1500V AC/Minute(Pitch 2.54mm)
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -40℃ to 105℃
Reference
Use in HID ballast's connector
