Specifications
Current rating: 4.0A (AWG 22), 12A (AWG 16), 16.0A (AWG 14)
Voltage Range: 600V AC,DC
Withstand Voltage: 2500V AC/Minute
Insulation Resistance: 5000 MΩ Min.
Contact Resistance: 25 mΩ Max. before environment test
Temperature Range: -40℃ to 105℃
Reference
Mates with 66015S Housing
Applicable P.C. Board Thickness: 1.6 mm
