Specifications
Current rating: 4.0A (AWG 20), 16.0A (AWG 14)
Voltage Range: 250V AC,DC
Withstand Voltage: 2000V AC/Minute
Insulation Resistance: 5000 MΩ Min.
Contact Resistance: 5 mΩ Max. before
environment test
Temperature Range: -40℃ to 105℃
Accept Wire Size: AWG 14 to AWG 20
Reference
Mates with 66102S, 66102S Series Housing
Accept 66101TM Series Termina
