Specifications
Current rating: 16A Max. (AWG 14)
Voltage Range: 250V AC,DC
Withstand Voltage: 1000V AC/Minute
Insulation Resistance: 1000 MΩ Min.
Contact Resistance: 5 mΩ Max. before environment test
Temperature Range: -25℃ to 85℃
Accept Wire Size AWG 14 to AWG 22
Reference
Mates with 3301T, 3302T Terminal
Accept 66101T Series Terminal
