Specifications
Current rating: 4.0A (AWG 20), 12.0A (AWG 16)
Voltage Range: 250V AC,DC
Withstand Voltage: 2000V AC/Minute
Insulation Resistance: 5000 MΩ Min.
Contact Resistance: 5 mΩ Max. before environment test
Temperature Range: -40℃ to 105℃
Applicable PC Board Thickness: 1.6mm
Reference
Mates with 66102S F-Type Housing
