Specifications
Current rating: 1A AC/DC Max.
Voltage Range: 250V AC,DC
Withstand Voltage: 500V AC/Minute
Contact Resistance: 20 mΩ Max. before environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -40℃ to 105℃
Hole Dia. Of PC Board: 1.0mm
40 Pins Max for Single-Row
80 Pins Max. for Dual-Rows
Applicable PC Board Thickness: 1.6mm
Reference
Mates with 7337P Receptacle Header
Material
BASE: PBT 94V-0, Black color
PIN: Brass
High HDT Nylon 94V-0 is available
