Specifications
.Current rating: 1A AC,DC Max. (AWG 26)
.Voltage Range: 125V AC,DC
.Withstand Voltage: 250V AC/Minute
.Contact Resistance :20 mΩ Max. before Environment test
.Insulation Resistance: 100 MΩ Min.
.Temperature Range: -40℃ to 85℃
Applicable PC Board Thickness: 0.6~1.2mm
Reference
.Mates with 1250S Housing
.Certifications: UL, CSA
