Specifications
Current rating: 1A AC,DC Max. (AWG 24)
Voltage Range: 3000V AC,DC
Withstand Voltage: 5000V AC/Minute
Contact Resistance: 10 mΩ Max. before environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -40℃ to 105℃
Reference
Mates with 3502P Pitch 13.0 Header
Use with 3503T011R Crimp Terminal
Applicable Wire Gauge: UL3239 AWG 22~28
