Specifications
.Current rating: 1A AC,DC Max. (AWG 26)
.Voltage Range: 50V AC,DC
.Withstand Voltage: 500V AC/Minute
.Contact Resistance: 20 mΩ Max. before Environment test
.Insulation Resistance: 500 MΩ Min.
.Temperature Range: -25℃ to 85℃
Reference
.Mates with 1501P,1502P Headers
.Use with 1503T Terminal
.Certifications: UL, CSA
