Specifications
.Current rating: 4A AC/DC Max. (AWG 22)
.Voltage Range: 125V AC,DC
.Withstand Voltage: 1000V AC/Minute
.Contact Resistance: 10 mΩ Max. before Environment test
.Insulation Resistance: 1000 MΩ Min.
.Temperature Range: -30℃ to 105℃
Reference
.Mates with 2021P, 2022P Header
.Use with 2023T Terminal
.Certifications: UL, CSA
