Specifications
.Current rating: 3A AC/DC Max. (AWG 22)
.Voltage Range: 250V AC,DC
.Withstand Voltage: 800V AC/Minute
.Contact Resistance: 10 mΩ Max. before Environment test
.Insulation Resistance: 1000 MΩ Min.
.Temperature Range: -40℃ to 105℃
.Applicable PC Board Thickness: 1.6mm
.Material of Housing: High HDT Nylon 94V-0
.Material of Contact: Brass, Matte Tin-plated
Reference
.Mates: 2050S Housing
.Certifications: UL , CSA
