Specifications
.Current rating: 2A AC/DC Max. (AWG 24)
.Voltage Range: 100V AC,DC
.Withstand Voltage: 800V AC/Minute
.Contact Resistance: 10 mΩ Max. before Environment test
.Insulation Resistance: 1000 MΩ Min.
.Temperature Range: -25℃ to 85℃
.Applicable PC Board Thickness: 1.6mm
Reference
.Mates with 2001S Housing
.Certifications: UL , CSA
