Specifications
.Current rating: 2A AC/DC Max. (AWG 22)
.Voltage Range: 250V AC,DC
.Withstand Voltage: 750V AC/Minute
.Contact Resistance: 10 mΩ Max. before environment test
.Insulation Resistance: 500 MΩ Min.
.Temperature Range: -20℃ to 95℃
.Applicable PC Board Thickness: 1.6mm
Reference
.Mates with 6202P,6203P Header
.Use with 6203T Terminal
.Certifications: UL , CSA
