Specifications
Current rating: 3A AC/DC Max. (AWG 22)
Voltage Range: 350V AC,DC
Withstand Voltage: 1000V AC/Minute
Contact Resistance: 20 mΩ Max. before environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -55℃ to 125℃
Applicable PC Board Thickness: 1.6mm
Reference
Mates with 2580S Type-C Single-Row Housing
