Specifications
Current rating:5A AC/DC Max. (AWG 22)
Voltage Range: 250V AC,DC
Withstand Voltage: 750V AC/Minute
Contact Resistance: 6 mΩ Max. before environment test
Insulation Resistance: 5000 MΩ Min.
Temperature Range: -55℃ to 105℃
Wire Size: 22 AWG, 24 AWG, 26 AWG, 28 AWG
Reference
Mates with 2631P, 2632P Headers
Mates with 2630P Series IDC Receptacle Connector
