Specifications
Current rating: 7A AC/DC Max. (AWG 18)
Voltage Range: 250V AC,DC
Withstand Voltage: 1500V AC/Minute
Insulation Resistance: 1000 MΩ Min.
Contact Resistance: 10 mΩ Max. before environment test
Temperature Range: -40℃ to 105℃
Applicable PC Board Thickness: 1.6mm
Reference
Mates with 3060S Type-0, 1, 3, C, D Housing
