Specifications
Current rating: 7A AC/DC Max. (AWG 18)
Voltage Range: 250V AC,DC
Withstand Voltage: 1500V AC/Minute
Insulation Resistance: 1000 MΩ Min.
Contact Resistance: 6 mΩ Max. before environment test
Temperature Range: -40℃ to 105℃
Material: Nylon66 UL 94V-0, Natural (White)
Reference
Mates with 3061P, 3062P Headers
Use with 3360T02 Terminal
