Specifications
Current rating: 10A AC/DC Max. (AWG 16 / 2 Ports)
Voltage Range: 300V AC,DC
Withstand Voltage: 2200V AC/Minute
Contact Resistance: 10 mΩ Max. before environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -40℃ to 105℃
Reference
Mates with 3941P, 3942P Headers
Use with 3943TF Terminal
Material: Nylon 66 94V-0, Natural
