Specifications
Current rating: 12A AC/DC Max. (AWG 16)
Voltage Range: 250V AC,DC
Withstand Voltage: 1500V AC/Minute
Insulation Resistance: 1000 MΩ Min.
Contact Resistance: 10 mΩ Max. before environment test
Temperature Range: -40℃ to 105℃
Reference
Mates with 3961P,3962P Header
Material: Heat nylon 66 94V-0, Light Ivory Color
