Specifications
Current rating: 1A AC,DC Max.
Voltage Range: 1400V AC,DC (Pitch 3.5)
Voltage Range: 1800V AC,DC (Pitch 8.0)
Withstand Voltage: 3800V AC/Minute
Insulation Resistance: 1000 MΩ Min.
Contact Resistance: 10 mΩ Max. before environment test
Temperature Range: -25℃ to 85℃
Applicable PC Board Thickness: 1.6 mm
Reference
Mates with 4000S0300 Housing (Pitch 8.0)
Mates with 3500S0200 Housing (Pitch 3.5)
