Specifications
Current rating: 1A AC,DC Max. (AWG 22)
Voltage Range: 1400V AC,DC
Withstand Voltage: 3800V AC/Minute
Contact Resistance: 10 mΩ Max. before environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -25℃ to 85℃
Material: Nylon 66 94V-0, Natural (White) color
Reference
Mates with 3502P Headers, 3500S0210-1 Housing
Use with 3503T Terminal
Applicable Wire Gauge: UL3239 AWG 22~28
