Specifications
.Current rating: 3A AC/DC Max. (AWG 22)
.Voltage Range: 250V AC,DC
.Withstand Voltage: 800V AC/Minute
.Contact Resistance: 10 mΩ Max. before Environment test
.Insulation Resistance: 1000 MΩ Min.
.Temperature Range: -25℃ to 85℃
.Applicable PC Board Thickness: 1.6mm
.Material: Nylon 66 94V-0, Nature
Reference
.Mates with 2051P, 2052P Header
.Use with 2053T Terminal
.Certifications: UL, CSA
