Specifications
.Current rating: 3A AC/DC Max. (AWG 22)
.Voltage Range: 250V AC,DC
.Withstand Voltage: 1000V AC/Minute
.Contact Resistance: 20 mΩ Max. before environment test
.Insulation Resistance: 1000 MΩ Min.
.Temperature Range: -40℃ to 105℃
Reference
.Mates with 2640S Series Housing
.Use with 2643TM Terminal
.Certification: UL, CSA
