Specifications
Current rating: 1A AC/DC Max. (AWG 22)
Voltage Range: 200V AC,DC
Withstand Voltage: 650V AC/Minute
Contact Resistance: 15 mΩ Max. before environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -55℃ to 85℃
Reference
Mates with 2570M, 7305P,7306P Headers
Use with 2583T1 Series Terminal
Applicable Wire Range: 22 AWG to 24 AWG
