Specifications
Current rating: 8A AC/DC Max. (AWG 16)
Voltage Range: 600V AC,DC
Withstand Voltage: 1500V AC/Minute
Contact Resistance: 10 mΩ Max. before environment test
Insulation Resistance: 1000 MΩ Min.
Temperature Range: -40℃ to 105℃
Material: Nylon 66 UL 94V-0 / 94V-2
Reference
Mates with 4200F Plug Housing
Use with 4203TM Terminal
